Mini Excavators LJ15 1.5Ton
- Product description
-
LJ15
Overall Size (Unit: MM)
Scope of Work (Unit: MM)
Wheel tread
935
Maximum ground digging radius
2815
Total length of track
1235
Maximum digging depth
1735
Platform ground clearance
380
Maximum digging height
2585
Platform rear turning radius
870
Maximum dumping clearance
1810
Chassis width
1000
Maximum vertical digging depth
1030
Track width
175
Minimum swing radius
1390
Track height
320
Maximum lifting height of bulldozer
295
Transport length
2590
Maximum digging depth of bulldozer
270
Height of seat to ground
1560
Full vehicle height
2190
Performance Parameter
Weight of the machine kg
1500
Standard bucket capacity m3
0.03
Form of working device
Backhoe
Engine
Model
KEPU 292
KUBOTA 722
Displacement L
0.997
0.719
Power (KW) / Speed (rpm)
15.5/3000
16.5/3600
8.9/22001
4.9/3600
Maximum torque (NM)/Speed (rpm)
48/2700
45/2800
Speed and digging power
Maximum traveling speed(km/h)
2.4
Swing speed (rpm)
9
Maximum grade ability
30° (58% )
Bucket digging force KN
10.5
Arm digging force KN
7.2
Maximum drawbar pull KN
12.2
Grounding pressure KPa
25.6
Track material
Rubber
Track tensioning device type
Screw tensioning
Hydraulic and liquid capacity
Pump type
Gear pump
Work stress MPa
18
Flow L/min
16
Hydraulic oil tank capacity L
14
Maximum (effective) engine oil capacity L
2.75/1.8
Fuel tank capacity L
10
Production capacity
The company has a modern production workshop and advanced manufacturing equipment, which provides a reliable guarantee of product quality and production efficiency. We manage production in strict accordance with the ISO9001 quality management system to ensure that each link meets quality standards. At the same time, we also have advanced testing equipment and strict quality control processes to ensure product standardization.
Research and development capabilities:
The company has established a good reputation in the field of scientific research, has a high-quality and professional R&D team, and holds a number of invention patents. Team members possess rich industry experience and professional knowledge and are committed to technological innovation and modernization of excavators and cylindrical equipment.
Keyword:
Mini Excavators LJ15 1.5Ton
FAQ
The content of the excavator is as follows
Question 1: The warranty period of the excavator
Answer: One year or 2,000 hours
Question 2: Can replacement parts be found in the customer's country?
Answer: Yes. (We provide some small accessories for free.)
Question 3: Can customized services be provided?
Answer: Yes. (We can offer color customization and logo customization.)
Question 4: What kind of engine is adopted?
Answer: Chinese engines or imported engines (as per customer requirements)
Engines are classified into single-cylinder engines, two-cylinder engines and three-cylinder engines
Question 5: What are the modes of transportation?
Answer: Ocean transportation, railway transportation and road transportation
For ocean transportation, we are not responsible for customs clearance and tariffs. We only handle delivering the goods to ports (such as the Port of St. Petersburg and the Port of Vladivostok).
For railway and road transportation, we are responsible for customs clearance and tariffs. If the customer needs it, it can be delivered directly to the door
The contents of the hydraulic cylinder are as follows
Question 6: The materials that need to be provided by the customer before making a quotation
Answer: Hydraulic cylinder number/parameter photo/Hydraulic cylinder floor plan (It is best to provide two sets of materials)
3D design drawings of hydraulic cylinders can be made (only design drawings are required, but an additional charge applies. If you place an order for purchase, it can be free of charge).
Question 7: Can customized services be provided?
Answer: Yes. (We can offer color customization and logo customization.)
Question 8:
Payment Method:
Question 9: Transaction process
We offer quotations. The customer pays a 30% advance payment and the factory arranges for production. After the factory production is completed, we will provide a video for the customer to confirm the status of the goods. Once confirmed to be correct, the customer will pay 70% of the balance. After the factory receives the payment for goods, we will deliver the goods.
Question 10: Payment Account
Company payment: If payment is made through a company account, we can provide a company account (VTB account).
If it is an individual payment, we can provide a personal account (only accepting rubles).
The time for the funds to arrive: generally, it is 1 to 3 days
